N-type Connector High Quality Cavity Power Splitter
Release time：2015/10/10 From：NANJING SAIGEW MICROELECTRONICS & TECHNOLOGY CO., LTD. Browse：1140
Category classification： Couplers&Power Splitters&Bridge
Content of product detail：
|
P/N
|
SPL-0727-02G
|
SPL-0727-03G
|
SPL-0727-04G
|
|
Frequency Range
|
700～2700MHz
|
||
|
Insertion Loss （dB）
|
≤3.3dB
|
≤5.2dB
|
≤6.4dB
|
|
VSWR
|
≤1.2
|
≤1.25
|
≤1.32
|
|
Passband Ripple（dB）
|
≤0.3dB
|
≤0.4dB
|
≤0.4dB
|
|
PIM
|
PIM3≤-155dBc@2×43dBm
|
||
|
PIM5≤-165dBc@2×43dBm
|
|||
|
Impedance（Ω）
|
50Ω
|
||
|
Connector
|
NK
|
||
|
Average Power（W）
|
≥300W
|
||
|
Peak Power（W）
|
≥1000W
|
||
