BTW-120LTAF
Release time：2015/10/10 From：NANJING SAIGEW MICROELECTRONICS & TECHNOLOGY CO., LTD. Browse：738
Category classification： Ferrite Isolators&Circulators
Content of product detail：
|
P/N
|
BTW-120LTAF
|
|
|
Frequency
|
10.95-12.75GHz
or 12.25-12.75 GHz
|
|
|
|
Normal Temp.
|
Over Temp.
|
|
Isolation
|
≥25dB
|
≥22dB
|
|
Insertion Loss
|
≤0.25dB
|
≤0.35dB
|
|
VSWR
|
≤1.2
|
≤1.3
|
|
Temp.
|
-40～+70℃
|
|
|
Connector
|
BJ120→W(180 degrees transmission)
|
|
|
Material
|
Housing Waterproof
|
|
