High Quality Cavity Coupler
Release time：2015/10/10 From：NANJING SAIGEW MICROELECTRONICS & TECHNOLOGY CO., LTD. Browse：1111
Category classification： Couplers&Power Splitters&Bridge
Content of product detail：
Directional Coupler
|
P/N
|
CUL-0727-15dBDG
|
CUL-0727-20dBDG
|
CUL-0727-25dBDG
|
CUL-0727-30dBDG
|
CUL-0727-35dBDG
|
CUL-0727-40dBDG
|
|
Frequency (MHz)
|
700-2700
|
|||||
|
Coupling(dB)
|
15±1
|
20±1
|
25±1
|
30±1
|
35±1.5
|
40±1.5
|
|
Insertion Loss(dB)
|
0.4
|
0.4
|
0.3
|
0.3
|
0.3
|
0.3
|
|
Direction(dB)
|
≥18
|
≥15
|
||||
|
VSWR
|
≤1.25
|
|||||
|
Power(W)
|
500
|
|||||
|
IMD3
|
＜-155dBc(+43dBm×2)
|
|||||
|
IMD5
|
＜-165dBc(+43dBm×2)
|
|||||
|
Temp.(℃)
|
-20～+50
|
|||||
|
Impedance(Ω)
|
50
|
|||||
|
Connector
|
DINK
|
|||||
|
IP Rating
|
IP65
|
|||||
